Recombinant hirudin has been found to be immunogenic in patients treated with lepirudin following heparin-induced thrombocytopenia (HIT). We assessed the incidence of immunoglobulin G (IgG) antihirudin antibodies by enzyme-linked immunosorbent assay in 112 patients enrolled in a dose-finding study with desirudin. Patients received desirudin subcutaneously following orthopedic hip surgery at 10 mg twice a day (n = 17), 15 mg twice a day (n = 75), and 20 mg twice a day (n = 20). Of 112 patients, 11 (9.8%) developed antihirudin antibodies independently of the dose. The rate of immunization did not differ from that observed in HIT patients treated with lepirudin (P = .113). Plasma concentrations of desirudin did not differ between antihirudin antibody–positive and –negative patients. Antihirudin antibodies had no impact on incidences of deep vein thrombosis and/or pulmonary embolism, allergic reactions, and hemorrhage. However, the total number of immunized patients observed was low and so infrequent (but severe) effects of antihirudin antibodies cannot be excluded.

There are 2 recombinant hirudins approved in the European Union: desirudin (Revasc; Aventis, Frankfurt, Germany) and lepirudin (Refludan; Schering, Berlin, Germany). Desirudin is approved for thrombosis prophylaxis following orthopedic hip-replacement surgery and lepirudin for anticoagulation in patients with heparin-induced thrombocytopenia (HIT) and thromboembolic complications. Both compounds differ from each other in their N-termini: desirudin possesses a valine-valine and lepirudin a leucine-threonine structure. Otherwise the desirudin and lepirudin are very similar, with molecular weights of 6.96 kDa and 6.98 kDa, respectively.

Rhesus monkeys did not show a specific immune response following intravenous boluses of desirudin.1 In contrast, balb/c mice showed a 100% antihirudin antibody response after immunization by albumin-conjugated hirudin or hirudin fragments.2,3 Also, dogs generated antihirudin antibodies following immunization with desirudin.4

In healthy volunteers, a few allergic reactions were observed following intravenous as well as subcutaneous applications of desirudin.5 Allergic reactions occurred in 3 volunteers, in another 4 the skin test became positive. In one volunteer antihirudin antibodies were detected.

In none of the major clinical studies of patients with acute coronary syndromes was an immune reaction toward 1 of the 2 hirudins reported.6-10 However, these patients were usually treated for 2 to 3 days only, which is too short of a period for a B-cell response.

In 1996, we reported that a high proportion of patients receiving lepirudin for HIT developed antihirudin antibodies,11,12 a finding confirmed by others.13,14 During a mean duration of treatment of 14.4 days, 44% of 198 patients treated with lepirudin developed antihirudin antibodies of the immunoglobulin G (IgG) class, which occurred as early as day 4 (peak at days 8-9). Of 87 patients with detectable antihirudin antibodies, 61 (70.1%) developed during treatment, 23 (26.4%) occurred after cessation of lepirudin, and 3 (3.5%) became positive during a second treatment course with lepirudin only.12

In another study with lepirudin given to patients with HIT (up to 26 days), up to 74% of patients developed antihirudin antibodies of the IgG, IgA, and/or IgM class.13,14 None of these patients developed allergic reactions.

Desirudin is approved for thrombosis prophylaxis following orthopedic hip-replacement surgery based on 3 prospective trials.15-17 These patients usually require treatment for 7 to 10 days, which is within the time frame for induction of antihirudin antibodies. The purpose of the present study was to assess whether desirudin given subcutaneously in prophylactic dose in patients following orthopedic hip-replacement surgery is immunogenic, and to compare the outcomes of patients testing positive and negative for antihirudin antibodies.

Patients

Patients were enrolled in a prospective dose-finding study, as described elsewhere.15 Approval was obtained from the Göteborg University and the Greifswald University institutional ethics boards for these studies. Informed consent was provided according to the Declaration of Helsinki. Serum was obtained between days 6 and 11 after start of desirudin (mean day, 8 ± 1). Samples were frozen at −30°C or below.

Hirudins

Desirudin was provided by Novartis Pharma (Nürnberg, Germany) and lepirudin, by Aventis.

Laboratory assays

Antihirudin antibody enzyme-linked immunosorbent assay (ELISA) was performed as described.12 Microtiter wells (Covalink, Nunc, Germany) coated with desirudin or lepirudin were incubated with patient plasma (1:50 for 60 minutes at 37°C), and IgG binding assessed by anti-human IgG-peroxidase labeled antibodies. Sera of HIT patients with known antihirudin antibodies served as positive controls, plasma of healthy blood donors served as negative controls. The assay was performed by personnel blinded for the dose of desirudin given to the patients.

Concentrations of free desirudin in patient plasma samples were assessed by a chromogenic assay using the thrombin substrate S2238, as described previously.18

Incidences of deep vein thrombosis and pulmonary embolism, allergic reactions, and hemorrhages were compared by Fisher exact test (2-tailed). Occurrence of antihirudin antibodies over time was calculated by Kaplan-Meier statistics. Plasma concentrations of antihirudin antibody–positive and –negative patients were compared by Wilcoxon rank-sum test.

Samples from 112 patients were studied of 20 patients who received a dosage of 20 mg desirudin subcutaneously twice a day, of 75 patients who received a dosage of 15 mg subcutaneously twice a day, and of 17 patients who received a dosage of 10 mg subcutaneously twice a day.

In 11 (9.8%) of 112 patients, antihirudin antibodies were detectable. Results were identical whether desirudin or lepirudin was used in the ELISA, indicating a 100% cross-reactivity. Seroconversion rates were similar among the 3 dosing groups: 2 (10%) of 20 patients received 20 mg desirudin twice a day, 6 (8.0%) of 75 patients received 15 mg twice a day, and 3 (17.6%) of 17 patients received 10 mg twice a day. Compared with the occurrence of antihirudin antibodies in HIT patients treated with lepirudin, no differences were observed (P = .113, log-rank test, Figure1).

Fig. 1.

Occurrence of antihirudin antibodies in relation to treatment duration.

Desirudin-treated patients (N = 112, thin line); lepirudin-treated patients (N = 198, bold line).

Fig. 1.

Occurrence of antihirudin antibodies in relation to treatment duration.

Desirudin-treated patients (N = 112, thin line); lepirudin-treated patients (N = 198, bold line).

Close modal

Desirudin plasma concentrations of antihirudin antibody-positive patients did not differ from those of antihirudin antibody-negative patients within the 3 dosing groups: (1) 10 mg, 0.1 μg/mL versus 0.094 μg/mL, respectively (P = 1.0); (2) 15 mg, 0.17 μg/mL versus 0.28 μg/mL, respectively (P = .33) and (3) 20 mg, 0.1 μg/mL versus 0.17 μg/mL, respectively (P = .63).

Clinical end points could be evaluated in 109 patients. Outcomes of antihirudin antibody–positive patients did not differ compared with antihirudin antibody–negative patients: deep vein thrombosis and/or pulmonary embolism, 2 (18.2%) of 11 vs 11 (10.9%) of 101,P = .61; allergic reactions, 0 of 11 vs 1 of 101,P = 1.0; hemorrhage, 1 (9.1%) of 11 vs 6 (5.9%) of 101,P = .53.

The present study shows that subcutaneous desirudin is immunogenic in patients after major orthopedic surgery. At day 8 of treatment, approximately 10% of patients are immunized. Numerically this rate is much lower than the rate observed in patients with HIT receiving lepirudin.12-14 However, using Kaplan-Meier calculation, the risk of immunization per time exposed seems to be identical in both patient populations (Figure 1). Thus the total rate of immunization depends on treatment duration and time point of blood sampling.

The 2 hirudins differ in the structure of the N-terminal part. However, antibodies of patients treated with desirudin showed a 100% cross-reactivity to lepirudin and vice versa, and therefore must recognize structures common to both hirudins with the same immunogenicity.

Also, different routes of application (intravenous versus subcutaneous) are of no relevance for immunization; in the present study, patients received hirudin only subcutaneously, whereas lepirudin was given only intravenously in HIT patients.

As the dose was higher in lepirudin-treated patients (approximately 250 mg per day in a 70-kg patient) compared with the present study, immunization is not dose related, at least if 10 mg twice a day is given.

The result is surprising as the 2 patient groups are very different. We suspected HIT patients to be more likely to form antihirudin antibodies, because they have already formed antibodies toward platelet factor 4/heparin complexes. This indicates that HIT patients do not have an increased tendency to form antibodies to other drugs.

Antihirudin antibody desirudin complexes cannot be filtered by the glomeruli. However, neither a difference in desirudin plasma levels, nor in bleeding complications, could be observed between antihirudin antibody–positive and –negative patients. Also we found no evidence for inhibitory antibodies, which have been described in HIT patients receiving lepirudin.12,19 Because of the small numbers of immunized patients, this observation must be considered preliminary.

In conclusion, desirudin given in prophylactic dose in patients after orthopedic hip-replacement surgery is immunogenic. The overall risk of immunization seems to be the same as in HIT patients receiving lepirudin in therapeutic dose. As the treatment and observation period was shorter in the present study, the percentage of immunized patients was lower. The overall number of immunized patients, however, is still small, and thus less frequent severe adverse effects might have been overlooked until now. Patients under treatment should be carefully observed for adverse events.

Prepublished online as Blood First Edition Paper, October 17, 2002; DOI 10.1182/blood-2002-04-1055.

Supported by Deutsche Forschungsgemeinschaft DFG Gr1096/2-3a and by a grant from Novartis Pharma and by the German Federal Ministry for Education and Research (NBL3 program, reference 01 ZZ0103).

The publication costs of this article were defrayed in part by page charge payment. Therefore, and solely to indicate this fact, this article is hereby marked “advertisement” in accordance with 18 U.S.C. section 1734.

1
Bichler
J
Gemmerli
R
Fritz
H
Studies for revealing a possible sensitization to hirudin after repeated intravenous injections in baboons.
Thromb Res.
61
1991
39
51
2
Schlaeppi
JM
Vekemans
S
Rink
H
Chang
JY
Preparation of monoclonal antibodies to hirudin and hirudin peptides.
Eur J Biochem.
188
1990
463
470
3
Schlaeppi
JM
Preparation of monoclonal antibodies to the thrombin/hirudin complex.
Thromb Res.
62
1991
459
470
4
Gygax
D
Botta
L
Ehrat
M
et al
Immunoassays in monitoring biotechnological drugs.
Ther Drug Monit.
18
1996
405
409
5
Close
P
Bichler
J
Kerry
R
et al
Weak allergenicity of recombinant hirudin CGP 39393 (Revasc) in immunocompetent volunteers: The European Hirudin in Thrombosis Group (HIT Group).
Coron Art Dis.
5
1994
943
949
6
Zoldhelyi
P
Webster
MW
Fuster
V
et al
Recombinant hirudin in patients with chronic, stable coronary artery disease: safety, half-life, and effect on coagulation parameters.
Circulation.
88
1993
2015
2022
7
Topol
EJ
Fuster
V
Harrington
RA
et al
Recombinant hirudin for unstable angina pectoris: a multicenter randomized angiographic trial.
Circulation.
89
1994
1557
1566
8
Van den Bos
AA
Deckers
JW
Heyndrickxs
GR
et al
Safety and efficacy of recombinant hirudin (CGP 39393) versus heparin in patients with stable angina undergoing coronary angioplasty.
Circulation.
88
1993
2058
2066
9
Organization to Assess Strategies for Ischemic Syndromes (OASIS) Investigators
Comparison of the effects of two doses of recombinant hirudin compared with heparin in patients with acute myocardial ischaemia without ST elevation: a pilot study.
Circulation.
96
1997
769
777
10
Organization to Assess Strategies for Ischemic Syndromes (OASIS-2) Investigators
Effects of recombinant hirudin (lepirudin) compared with heparin on death, myocardial infarction, refractory angina, and revascularization procedures in patients with acute myocardial ischaemia without ST elevation: a randomized trial.
Lancet.
353
1999
429
438
11
Eichler
P
Greinacher
A
Anti-hirudin antibodies induced by recombinant hirudin in the treatment of patients with heparin-induced thrombocytopenia (HIT).
Ann Hematol.
72(suppl 1)
1996
21
12
Eichler
P
Friesen
HJ
Lubenow
N
Jaeger
B
Greinacher
A
Antihirudin antibodies in patients with heparin-induced thrombocytopenia treated with lepirudin: incidence, effects on aPTT, and clinical relevance.
Blood.
96
2000
2373
2378
13
Song
XH
Huhle
G
Wang
LC
Hoffmann
U
Harenberg
J
Generation of anti-hirudin antibodies in heparin-induced thrombocytopenic patients treated with r-hirudin.
Circulation.
100
1999
1528
1532
14
Huhle
G
Hoffmann
U
Song
X
Wang
LC
Heene
DL
Harenberg
J
Immunologic response to recombinant hirudin in HIT type II patients during long-term treatment.
Br J Haematol.
106
1999
195
201
15
Eriksson
BI
Ekman
S
Kaelebo
P
Zachrisson
B
Bach
D
Close
P
Prevention of deep-vein thrombosis after total hip replacement: direct thrombin inhibition with recombinant hirudin, CGP 39393.
Lancet.
347
1996
635
639
16
Eriksson
BI
Wille-Jørgensen
P
Kälebo
P
et al
A comparison of recombinant hirudin with a low-molecular-weight heparin to prevent thromboembolic complications after total hip replacement.
N Eng J Med.
337
1997
1329
1335
17
Eriksson
BI
Ekman
S
Lindbratt
S
et al
Prevention of thromboembolism with use of recombinant hirudin: results of a double-blind, multicenter trial comparing the efficacy of desirudin (Revasc) with that of unfractionated heparin in patients having a total hip replacement.
J Bone Joint Surg Am.
79
1997
326
333
18
Pötzsch
B
Madlener
K
Seelig
C
Riess
CF
Greinacher
A
Müller-Berghaus
G
Monitoring of r-hirudin anticoagulation during cardiopulmonary bypass: assessment of the whole blood ecarin clotting time.
Thromb Hemost.
77
1997
920
925
19
Huhle
G
Liebe
V
Hudek
R
Heene
DL
Anti-r-hirudin antibodies reveal clinical relevance through direct functional inactivation of r-hirudin or prolongation of r-hirudin's plasma halflife.
Thromb Haemost.
85
2001
936
938

Author notes

Andreas Greinacher, Institut für Immunologie und Transfusionsmedizin, Ernst-Moritz-Arndt-Universität, Sauerbruchstr/Diagnostikzentrum, 17487 Greifswald, Germany; e-mail:greinach@uni-greifswald.de.
